Digital Type 70ft Electronic Truck Scale 100 Ton 8~20mm Steel Q235 Stable Performance

Basic Information
Place of Origin: Guangdong, China
Brand Name: KEDA
Certification: ISO CE
Model Number: SCS-60T
Minimum Order Quantity: 1 set
Price: USD9800~14500
Packaging Details: The platform of weighbridge is nude packed and the accessories are packed in cartons or wooden box
Delivery Time: 10~25 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200 Set/Sets per Month
Features: High Precision And Stable Performance Product Name: Industrial Weighbridge
Power Supply: 220V/50HZ, AC/DC Display Type: KELI D2008H
Type: Digital Type Capacity: 60T
Accuracy: 10KG Overload Protection: 150%F.S
Material: 8~20mm Steel Q235 Structure: U Beam Girders With 6pcs And 6mm Thickness
Load Cell: KELI Or Zemic With OMIL Certificated Use: Heavy Goods
Item: Weighbridge Display: LED/LCD
Warranty: 1 Year
High Light:

vehicle weight scales

,

vehicle weight machine

Chinese 70ft Exported Electronic Modular Weighbridge 100 Ton



Why choose our industrial weighbirdge?


More than 1000 Keda weighbridge had live through kinds of verifications. Their high quality had win customers trust. Now they are widely used in leather, steel, coal, grain, ceramic, chemical, dock and other industries.


Standard configuration of Industrial Weighbridge:


Weighbridge platform, high accuracy weighing load cells, weighing indicator, junction box and shield cable are necessary parts of one set weighbridge truck scale. Printer, scoreboard and computer management system are optional so as to complete the requirements of data management and transmission on the higher level.





Weighbridge Technical Paramater
Type Digital type
Platfrom size Length: 6~21m, width: 3~3.5m
Platform material 8-20mm thickness top steel plate
Painting poxy zinc rich primer and acrylic marine paint
Max. Cap From 30 ton to 150 ton
Accuracy OIML Ⅲ stardard
Safe over loade 150%F.S
Power supply 110V+-10%; 220V +-10% AC or DC, 50 or 60Hz
Load cell Keli digital load cell or ZEMIC digital load cell
Weighing indicator YAOHUA or Keda indicator
Working temperture -10~40ºC(indicator), -30~75ºC(load cell)
Working humidity ≤95%
Certificate CE, OIML, ISO9001:2015



Recommended dimension for KEDA truck scale platform
Capacity(Tons)
30
40
50
60
80
100
120
150

Division Value
5KG/10KG/20KG/50KG

Platform size:L*W(m)
Recommended size
Packing(container)
3*7






1x20'GP
3*9



1x20'GP
3*12



1x20'GP
3*14


1x20'GP
3*16



1x20'GP
3*18



1x20'GP
3*20




1x40'GP
3*22




1x40'GP
3*24




1x40'GP
Remark
Other capacity, size and apprearance can be customized according your requirements.
