Intelligent Electronic Weighbridge System Truck Scale 30 Ton To 150 Ton

Basic Information
Place of Origin: Guangdong, China
Brand Name: Keda
Certification: ISO
Model Number: SCS-150
Minimum Order Quantity: 1 set
Price: USD5000~14500
Packaging Details: The body of truck weight bridge is nude packed and the accessories are packed in cartons
Delivery Time: 10~25 days
Payment Terms: L/C, T/T
Supply Ability: 100 Set/Sets per Month
Material: Q235 Load Cell: Digital
Power Supply: 220V AC Or 9V DC Max. Capacity: 150 Ton
Division: 50kg Accuracy: OIML 3
Safe Overload: 150% Structure: U-shape Beams
Certificate: CE ISO9001 Interface: RS232C / Printer / PC
Place Of Origin: Guangdong, China Warranty: 1 Year
Software: Intelligent Weighing System
High Light:

truck scale weighbridge


computerized weighbridge

Truck Scale 30 Ton To 150 Ton Intelligent Electronic Weighbridge System


Standard configuration of KEDA SCS weighbridge:

Weighbridg platform, high accuracy weighing load cells, weight indicator, junction box and shield cable are necessary parts of a basic weighbridge. Printer, scoreboard and computer management system are optional so as to complete the requirements of data management and transmission on the higher level.


KEDA weighbridge is available in both surface and pit mount designs. Key features include:

Weighbridge Technical Paramater

Type Digital weighbridge
Platfrom size From 6m to 24m, width3.0m, 3.2m, 3.5m
Platform material 8-20mm thickness top steel plate
Painting poxy zinc rich primer and acrylic marine paint
Max. Cap 40 ton
Accuracy 10kg (OIML Ⅲ)
Safe over loade 150% F.S
Power supply 110V+-10%; 220V +-10% AC or DC, 50 or 60Hz
Load cell Keli digital load cell or ZEMIC digital load cell
Weighing indicator YAOHUA or Keda indicator
Interface RS232 (or RS485), PC, printer, extra scoreboard
Working temperture -10~40ºC(indicator), -30~75ºC(load cell)
Working humidity ≤95%
Certificate CE, OIML, ISO9001:2015



Recommended dimension for KEDA truck scale platform

Capacity(Tons) 30 40 50 60 80 100 120 150
Division Value 5KG/10KG/20KG/50KG
Platform size:L*W(m) Recommended size Packing(container)
3*7             1x20'GP
3*9       1x20'GP
3*12     1x20'GP
3*14     1x20'GP
3*16       1x20'GP
3*18       1x20'GP
3*20         1x40'GP
3*22           1x40'GP
3*24             1x40'GP
Remark Other capacity, size and apprearance can be customized according your requirements.
