| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | KEDA |
| Certification: | ISO CE |
| Model Number: | SCS-60T |
| Minimum Order Quantity: | 1 set |
| Price: | Negotiated price |
| Packaging Details: | The platform of truck scales is nude packed and the accessories are packed in cartons or wooden box |
| Delivery Time: | 10~25 days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 200 Set/Sets per Month |
| Product Name: | Vehicle Scales | Power Supply: | 220V/50HZ, AC/DC |
|---|---|---|---|
| Display Type: | KELI Or YAOHUA | Type: | Digital Type |
| Capacity: | 30T To 120T | Accuracy: | 10/20/50kg |
| Display: | LED/LCD | Warranty: | 1 Year |
| High Light: | vehicle weight scales,vehicle weight machine |
||
| Technical parameter | |
|---|---|
| Accuracy class | OMIL III |
| Weighing range | 10~120(t) |
| Safe overload | 150%F.S |
| Material | Q235 |
| Thickness | 8, 10, 12, 14mm (optional) |
|
Structure |
U shape bridge construction stucture (6mm thickness) |
|
Painting |
Anti rust and anti corrosion painting |
| Length | 5~24(m) |
| Width | 3m,3.2m,3.5m,4m |
| Safe overload | 150%Max |
| Input voltage | 110V±10%~220V±10%,AC |
| Input power frequency | 50Hz,60Hz |
| Power consumption | 12V,DC |
| Serial port | RS232 or RS485 are available to for computer interface and scoreboard interface |
| Printer interface | compatible parallel port |
| Relative humidity | <95% |
| Working temperature |
indicatior: -10+45 centigrade weighing platform and load cell: -30+65 centigrade |
| Delivery time | 10~20 days |
| Packing | 20GP or 40GP container |
